2026 New AMFLOW PL Carbon

Frame & Suspension:
Frame: Carbon fiber frame, lightweight and strong.
Fork: 2026 FOX 36 SL Performance, 160 mm travel, GRIP damper, 15x110 mm axle, 44 mm offset.
Rear Shock: FOX Float Performance, Trunnion mount (185×55 mm), EVOL air sleeve, 2-position adjustment.

Electric Assist System:
Motor: Avinox M1, 105 Nm torque.
Battery: 800 Wh Avinox built-in battery.
Display: 2-inch OLED touchscreen, integrated into the frame.
Wireless Controllers: Left & right handlebar Avinox controllers.
Charger: 12 A / 508 W fast charger, 75% charge in 1.5 hours.

Drivetrain & Braking:
Shifter & Derailleur: SRAM Eagle 70 Transmission (T-Type) 12-speed.
Chainring: SRAM Eagle Transmission E-MTB 34 T.
Crankset: DJI Avinox SL (M/L: 155 mm, XL/XXL: 160 mm).
Cassette: SRAM XS-1270, 10–52 T.
Brakes: Magura MT5, 4-piston calipers, HC brake lever, 203 mm MDR-C rotors.

Geometry (Size L Example):
Reach: 475 mm.
Stack: 628 mm.
Wheelbase: 1255 mm.
Chainstay: 445 mm.
Head Tube Angle: 64.5°.
Seat Tube Angle: 77°.

Power Modes:
Eco, Trail, Turbo, Auto, Boost.
Auto mode adjusts assist based on terrain.
Boost mode delivers up to 120 Nm torque and 1000 W peak power.

Weight:
Approx. 21.2 kg (Size L, may vary by configuration).
